Fork Models / Marzocchi MX Comp / MX Pro
Marzocchi MX Comp / MX Pro
Marzocchi Bomber MX Comp and MX Pro 2003–2008: Air, Coil, ETA, TAS, SL and Race models by year – 30mm seal kit, parts list, exploded drawing, oil volumes.
Cross-Country / Trail 2003–2008 Travel: 85–120mm 30mm stanchions
The Marzocchi MX family
MX Comp and MX Pro were Marzocchi’s 30 mm cross-country and trail forks from 2003 to 2008, with 85, 105 or 120 mm of travel. They are light single-crown forks for XC and trail riding — not downhill forks.
They followed the 2002 MXC and MXR forks (30 mm, 80 / 100 mm), which have their own parts lists. The 1991 MX 100 is an unrelated early fork (24 mm on the seal chart).
MX models by year
From the Marzocchi parts lists and technical documents in our archive (seal chart where no parts list exists):
| Year | MX Comp | MX Pro | Travel |
|---|---|---|---|
| 2003 | Comp Air, Comp Coil, Comp + ETA, Comp+ | Pro Air, Pro Coil, Pro + ETA, Pro+ | 85 / 105 mm |
| 2004 | Comp Air, Comp Coil, Comp + ETA, Comp+ | Pro Air, Pro Coil, Pro + ETA, Pro+ | 85 / 105 / 120 mm |
| 2005 | Comp Air, Comp Coil, Comp + ETA, Comp+ | Pro Air, Pro Coil, Pro + ETA, Pro+ | 85 / 105 / 120 mm |
| 2006 | Comp, Comp + ETA, Comp + TAS | Pro, Pro + ETA, Pro + TAS, Pro SL (+ Remote Control), Pro Race | 85–120 mm |
| 2007 | – | Pro ETA (chart), Pro LO RC (chart), Pro Race 85 | 85–120 mm |
| 2008 | – | Pro LO RC (chart) | 80–120 mm |
2003 and 2004 also had 29” versions (MX Comp Coil, Comp ETA and Pro ETA) built for Trek. All MX models have 30 mm stanchions.
How they differ, from Marzocchi’s technical instructions:
- 2006 MX Comp: air spring in both legs, SSV damping with internal rebound adjustment.
- 2005 MX Pro Coil: coil springs with air preload, SSVF damping with external rebound adjustment.
- 2006 MX Pro SL: air spring, TST cartridge.
- ETA locks the fork low for climbing; TAS changes travel (100–120 mm).
Which seal kit fits my MX?
All MX Comp and MX Pro models from 2003 to 2008 take the 30 mm m-arch kit — Seal Kit – 30mm m-arch (DZ-SK-30M). Every MX parts list and seal-chart line we have points to it; several years (2003 Comp + ETA, 2004 Pro Air and Pro + ETA, 2005 Comp Air, 2006 Pro SL and Pro + ETA) are confirmed by both.
Oil volumes from Marzocchi documents
All MX forks use SAE 7.5 oil (Marzocchi 550013):
- 2005 MX Comp Coil (85 / 105 / 120): 130 cc right, 130 cc left.
- 2006 MX Comp (85 / 105 / 120): 135 cc right, 135 cc left.
- 2005 MX Pro + ETA (85 / 105 / 120): 135 cc per leg.
- 2006 MX Pro SL 105: 40 cc right (TST cartridge leg), 145 cc left.
Drawing, parts list and manuals
The exploded drawing and the parts list below are for the 2004 MX Comp ETA 105. The documents section holds the MX parts lists for 2003–2007 and the technical instructions for 2005 and 2006; all of them are also in the fork documentation library.
Exploded View
Source: Marzocchi Technical Instructions — MX Comp ETA 105 2004
Click image to zoom
Spare Parts List
142 parts · MX Comp ETA 105 2004 · Source: Marzocchi Technical Manual
Spare part list
— MX Comp ETA 105 2004
| Ref. | Code | Description | Category | Q.ty | Shop |
|---|---|---|---|---|---|
| 1 | 818211/A | CROWN+STAN.TUB+STEEL STEM MX04 | Fork Crowns | 1 | — |
| 1 | 818211/E | CROWN+STAN.TUB+ALL.STEM MX 04 | Fork Crowns | 1 | — |
| 1 | 818211/R | CROWN+STACH.TUBES MX COMP 04 | Fork Crowns | 1 | — |
| 2 | 549072AD | ALUMINUM KNOB | Knobs & Dials | 1 | In stock |
| 5 | 701254/C | PLUG UNIT- MX+ETA 2004 | Hardware | 1 | — |
| 6 | 520363 | SCREW | Hardware | 1 | — |
| 6 | 528223 | O-RING | Hardware | 1 | — |
| 7 | 549077AD | ETA/ECC BLACK ALUMINUM KNOB 04 | Knobs & Dials | 1 | — |
| 8 | 701208/C | Air PLUG UNIT 30mm | Top Caps | 1 | In stock |
| 9 | 529179 | SPRING WASHER | Springs | 1 | — |
| 12 | 538113 | UPPER BUSHING DIA 30 | Bushing Kits | 2 | — |
| 15 | 528172NOK>B | OIL SEAL | Seal Kits | 2 | — |
| 16 | 533301 | DUST SEAL | Seal Kits | 2 | — |
| 16 | 538112 | LOWER BUSHING DIA 30 | Bushing Kits | 2 | — |
| 17 | 850779/C | BUSHINGS DIA 30 KIT | Bushing Kits | 1 | — |
| 17 | 5141189/C | SPRING KIT 80mm travel | Springs | 1 | In stock |
| 18 | 524127>A | PISTON RING | Cartridges | 1 | — |
| 19 | 5321182MY/M | MONOLITE 30/04- WHITE | Stanchions | 1 | — |
| 19 | 5321182RA/M | MONOLITE 30/04-GUN METAL GREY | Stanchions | 1 | — |
| 19 | 5321182RB/M | MONOLITE 30/04-GUN MET.G.FLAT | Stanchions | 1 | — |
| 19 | 5321182RP/M | MONOLITE 30/04-FLAT TITAN | Stanchions | 1 | — |
| 19 | 5321182RR/M | MONOLITE 30/04-FLAT BLACK | Stanchions | 1 | — |
| 19 | 5321182RS/M | MONOLITE 30/04-GLOSS ECO BLACK | Stanchions | 1 | — |
| 19 | 5321182RT/M | MONOLITE 30/04-SILVER | Stanchions | 1 | — |
| 20 | 547564 | RH+LH LABELS MXPRO 04-BLACK | Decals | 1 | — |
| 20 | 547565 | RH+LH LABELS MXPRO 04- SILVER | Decals | 1 | — |
| 23 | 523261 | STOP RING | Hardware | 2 | — |
| 23 | 5321130>B | FOOT NUT UNIT | Foot Nuts | 2 | — |
| 23 | 5141275 | SPRING K=6,50 | Springs | 1 | — |
| 23 | 5141275/C | SPRINGS KIT K=6,50 | Springs | 1 | — |
| 24 | 528226 | O-RING | Hardware | 2 | — |
| 26 | 5141131/C | REBOUND SPRING KIT | Springs | 1 | — |
| 28 | 521142IW>A | NUT | Hardware | 1 | — |
| 29 | 522069 | WASHER 3P 26.8X2 FE D32PIF. | Hardware | 1 | — |
| 30 | 523270 | STOP RING | Hardware | 1 | — |
| 32 | 528046 | O-RING | Hardware | 2 | — |
| 34 | 512098>C | FOOT BUFFER | Bumpers | 1 | — |
| 34 | 8031185/C | PUMPING ROD MXCOMP 04 - 105/120 | Hardware | 1 | — |
| 35 | 547466 | LABEL ETA | Decals | 1 | — |
| 36 | 516089>A | VALVE | Hardware | 1 | — |
| 39 | 5181268 | PRELOAD SLEEVE 15MM LONG | Springs | 1 | — |
| 42 | 5321106 | RUBBER | Bumpers | 1 | — |
| 43 | 5321158>A | CABLE GUIDE | Hardware | 1 | — |
| 44 | 5321114 | PIN ADAPTOR | Canti Posts | 2 | — |
| 45 | 850690 | OIL SEAL KIT M/ARCH | Seal Kits | 1 | — |
| 45 | 509107 | FERRULE | Hardware | 1 | — |
| 45 | 5321115QF | CANTILEVER PIN | Canti Posts | 2 | — |
| 49 | 703698KM/C | ETA CARTRIDGE MX 04-TRAVEL 105 | Cartridges | 1 | In stock |
